Material: ABS+PC
MOKOSmart MKGW7 BLE USB Gateway
$38.00
- BLE 5.0 connectivity
- Dual connectivity via WiFi or USB
- Compact and portable design for easy installation
- Bi-directional communication for remote management
- USB-powered for versatile deployment
- Large memory capacity (4M Flash, 512KB SRAM)
10 in stock
[vc_row][vc_column][vc_column_text css=””]
MKGW7 BLE USB Gateway
The MKGW7 is a mini BLE USB gateway that bridges Bluetooth devices with cloud servers. This compact, plug-and-play device efficiently collects data from nearby beacons and transmits it to servers via WiFi or USB. Leveraging Bluetooth 5.0, MKGW7 supports downlink communication for remote management of Bluetooth devices.
Ideal for healthcare, offices, and warehouses, MKGW7 gateway offers flexible configurations, including optional external antennas. It features ample memory and flexible data filtering, making it a powerful tool for real-time location services, condition monitoring, asset tracking, and personal safety management.[/vc_column_text][vc_video link=”https://youtu.be/nHGYdkaFlp0″ css=””][/vc_column][/vc_row][vc_row][vc_column width=”1/2″][vc_column_text css=””]
Instant deployment: plug and play
The MKGW7 is tiny but mighty. This USB stick-sized Bluetooth gateway plugs right into any USB port for power and data. No extra cables or adapters are needed. At just 43 x 24.7 x 11.4 mm, you can tuck it away almost anywhere, making it perfect for all sorts of environments.[/vc_column_text][/vc_column][vc_column width=”1/2″][vc_single_image image=”33779″ img_size=”large” css=””][/vc_column][/vc_row][vc_row][vc_column width=”1/2″][vc_single_image image=”33780″ img_size=”large” css=””][/vc_column][vc_column width=”1/2″][vc_column_text css=””]
Efficient data collection and dual connectivity
MKGW7 USB gateway offers flexible data transmission options. It can connect to your network via WiFi, supporting 802.11 b/g/n protocols with multiple security options. Alternatively, it can transmit data through its USB connection, ensuring adaptability to different network setups.[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width=”1/2″][vc_column_text css=””]
BLE 5.0 with Extended Range
Equipped with Bluetooth 5.0, the MKGW7 mini USB gateway supports 1M/2M/Coded LE PHY. It can scan for Bluetooth devices up to 200 meters away in open areas, making it ideal for large-scale deployments in warehouses or office spaces.[/vc_column_text][/vc_column][vc_column width=”1/2″][vc_single_image image=”33781″ img_size=”large” css=””][/vc_column][/vc_row][vc_row][vc_column width=”1/2″][vc_column_text css=””]
Applications of MKGW4 Outdoor Cellular Gateway
- Smart Office
- Warehouse
- Healthcare
[/vc_column_text][/vc_column][vc_column width=”1/2″][/vc_column][/vc_row][vc_row][vc_column][vc_text_separator title=”Features” title_align=”separator_align_left” color=”custom” border_width=”5″ css=”” accent_color=”#d4af37″][/vc_column][/vc_row][vc_row][vc_column][vc_column_text css=””]
- BLE 5.0 connectivity
- Dual connectivity via WiFi or USB
- Compact and portable design for easy installation
- Bi-directional communication for remote management
- Highly secure data transmission
- USB-powered for versatile deployment
- Large memory capacity (4M Flash, 512KB SRAM)
- Multiple data filtering options with JSON format support
[/vc_column_text][vc_text_separator title=”Specifications” title_align=”separator_align_left” color=”custom” border_width=”5″ css=”” accent_color=”#d4af37″][/vc_column][/vc_row][vc_row][vc_column][vc_column_text css=””]
Dimensions: 43.0x 24.7 x 11.4 mm
Antenna: 1* internal/external 2.4GHz BLE antenna
Material: TPU
Power: Type-A USB (5V/1A)
MCU: ESP32-C3-MINI-1(U)
Flash: 4M
WiFi Protocol: 802.11 b/g/n
Bluetooth Protocol: BLE 5.0 (support 1M/2M/Coded LE PHY)
Operating temperature: -20 ºC~ 50 ºC
Bluetooth Scanning Range: 200 meters (in open area)
Installation: Insert into USB port
Protocol: MQTT V3.1.1
Encryption: SSL/TLS
Format: JSON
